HORIZON WOOD FIREPLACE

HORIZON WOOD FIREPLACE

$6,499.00

SKU: OB04010 Category: Tags: , ,

Description

Beyond the Size!
This wood fireplace offers peace of mind due to the combination of energy efficiency and clean heating. A simple solution; its clean design suits any type of decor.

Large fireplace. Behind its large glass door, the 4.28 cubic foot combustion chamber can hold an impressive 60 lbs of wood.

Low emissions. This energy efficient fireplace complies with the EPA’s clean-air standards (only 1.6 g/hr of emissions) in particular through the intelligent air control mechanism is a patented design that optimizes combustion quality.

High efficiency. The Horizon fireplace is capable of heating large spaces and burns for 10 hours.

Discover the additional qualities of the Osburn Horizon wood fireplace

APPROVED FOR THE ISLAND OF MONTREAL

Government incentives may apply to this product.
LEARN MORE

*Note that the price displayed on the web includes the prairie style faceplate (OA10630) and the moulded refractory brick panels (AC02360) that are required components for this unit.
**Any installation must be done according to the data and drawings detailed in the owner’s manual.

90% of the last 10 product owners who have registered their warranty are satisfied with this product.



Additional information

Heating area

000 – 2, 1, 800 Ft2
Maximum heat output

000 BTU/h (27.8 kW), 95
Fuel Type

Dry cordwood (16" recommended)
Overall firebox volume-ft³

4.28
EPA loading volume-ft³

4.28
Maximum burn time ()

11 h
69 % (LHV) (5)

Optimum efficiency (6)(7)
70%

Optimum heat transfer efficiency (8)
69%

Average particulate emissions rate (9)
1.6 g/h

Average CO (10)
159.0 g/h

Combustion technology
Non-catalytic

High-efficiency certified appliance
Yes, EPA 2020 approved

Maximum log length
25"

Log positioning
Loading over width

Chimney diameter
15'

Baffle type
C-Cast or equivalent

Approved for a mobile home installation
No

Shipping Weight
560 lb (254 kg)

Door type
Ceramic glass

Glass surface – dimensions (Width X Height)
29 3/4" X 13 1/2"

Glass air-wash system
176

Overall dimension (Height)
43 3/8"

Overall dimension (Width)
50 3/4"

Overall dimension (Depth)
31 3/4"

Door opening – dimension (Height)
12 3/4"

Door opening – dimension (Width)
33"

Firebox – dimension (Height)
17"

Firebox – dimension (Width)
25 3/8"

Firebox – dimension (Depth)
17 7/8"

Moulded refractory bricks
Yes

USA standard (emissions)
EPA / ASTM WK47329

Canadian Standard (emissions)
CSA B415.1-10

USA standard (safety)
UL 127

Canadian standard (safety)
ULC-S610

Tested and listed as per applicable standards
Limited lifetime

American Metal
Nexvent

1" Solid Pack
S-2100+

2" Solid Pack
CF Sentinel (CF)

2" Solid Pack
United-States

Clearance – top (measured from the platform on which the appliance is installed)**
84"

84"
8"

Clearance – side wall
24"

24"
N.A.

* The information given on the certification label affixed to the appliance always overrides the information published in any other media (owner's manual, catalogues, flyers, magazines and/or web sites).
HSS

AC Triple Wall
HS

AC Triple Wall
DuraTech

1" Solid Pack
DuraTech Canada (DTC)

1" Solid Pack
DuraTech Premium

2" Solid Pack
Dura Plus HTC

2" Solid Pack
Dura Plus

AC Triple Wall
Temp Guard

1" Solid Pack
Champion Chimney System

1" Solid Pack
Rockford Chimney Systems

1" Solid Pack
Ventis

1" Solid Pack
Super Pro 2100 (ALT)

2" Solid Pack
Super Vent 2100 (JM)

2" Solid Pack
8" (20 cm)

Selkirk
