MATRIX 1900 WOOD INSERT

$2,699.00

SKU: OB01900 Category: Tags: , ,

Description

Treat your family to incomparable comfort with the Matrix 1900 wood-burning insert. Its magnificent cast-iron faceplate is adorned with a patterned upper louver and columns that frame its large door. Its discreet black wooden handle, air control with removable handle as well as flush mount blower disappear to leave room for the delicate details of its faceplate. Its large glass surface highlights a panoramic view of the flames to fully enjoy your moments near the fire.

The Matrix 1900 is a compact unit that has tapered top and sides for easy installation in smaller hearths. The deep bottom of its combustion chamber allows ash to accumulate and reduces the frequency of cleaning.

APPROVED FOR THE ISLAND OF MONTREAL

Government incentives may apply to this product.
LEARN MORE

*Any installation must be done according to the data and drawings detailed in the owner’s manual.

The first 4 owners who have registered their warranty are 100% satisfied with this product.

Additional information

Heating area

200 Ft2, 250 – 1
Maximum heat output

000 BTU/h (13.19 kW), 45
Fuel Type

Dry cordwood (16" recommended)
Overall firebox volume-ft³

1.1
EPA loading volume-ft³

1.03
Maximum burn time ()

7 h
80 % (LHV) (5)

Optimum overall efficiency (6)(7)
82%

Optimum heat transfer efficiency (8)
78 %

Average particulate emissions rate (9)
1.5 g/h

Average CO (10)
34 g/h

Combustion technology
Non-catalytic

High-efficiency certified appliance
Yes, EPA 2020 approved

Maximum log length
17"

Log positioning
Loading over width

Chimney diameter
6"

Type of chimney
12'

Baffle type
C-Cast or equivalent

Approved for a mobile home installation
No

Shipping Weight
332 lb (151 kg)

Door type
Ceramic glass

Glass surface – dimensions (Width X Height)
18" X 8 1/8"

Glass air-wash system
90

Overall dimension (Height)
23 7/8"

Overall dimension (Width)
36"

Overall dimension (Depth)
21"

Door opening – dimension (Height)
7 7/8"

Door opening – dimension (Width)
18 1/4"

Firebox – dimension (Height)
8 7/8"

Firebox – dimension (Width)
16 3/4"

Firebox – dimension (Depth)
12 3/8"

Moulded refractory bricks
Yes

Steel thickness – body
3/16"

Fireplace opening – minimum (Height)
19"

Fireplace opening – minimum (Width)
25"

Fireplace opening – minimum (Depth)
15 1/2"

USA standard (emissions)
EPA

Canadian Standard (emissions)
CSA B415.1-10

USA standard (safety)
UL 1482, UL 737

Canadian standard (safety)
ULC S628

Tested and listed as per applicable standards
Limited lifetime

Minimum clearances to combustibles*(Data expressed in inches. 1 inch = 25.4 mm)
United-States

Clearance – top (measured from the platform on which the appliance is installed)**
72"

72"
1"

Clearance – combustible top mantle to unit
16"

Clearance – from the shelf to the base of the fireplace
34"

34"
