MATRIX WOOD STOVE WITH BLOWER

MATRIX WOOD STOVE WITH BLOWER

$3,799.00

SKU: OB02032 Category: Tags: , ,

Description

With the same sleek, modern style and vastly improved performance, the Matrix wood burning stove will certainly bring a European touch to your home. Let the Matrix wood stove provided you the warmth, safety and coziness needed during these cold winters

You can now personalize your device with the steel or soapstone top and side panel options from a local Quebec City mine, reminding us of the richness of our natural resources. Logs will easily fit under the large firebox, making the Matrix a practical and stylish heater. The Matrix is equipped with a 130 CFM fan to ensure optimal heat distribution. Enjoy the comfort of winter more than ever before!

Discover the additional qualities of the Matrix wood stove

APPROVED FOR THE ISLAND OF MONTREAL

Government incentives may apply to this product.
LEARN MORE

 *Any installation must be done according to the data and drawings detailed in the owner’s manual.

90% of the last 20 product owners who have registered their warranty are satisfied with this product.



Additional information

Heating area

100 Ft2, 500 – 2
Maximum heat output

000 BTU/h (22.0 kW), 75
Fuel Type

Dry cordwood (16" recommended)
Overall firebox volume-ft³

2.4
EPA loading volume-ft³

1.95
Maximum burn time ()

8 h
77 % (LHV) (5)

Optimum overall efficiency (6)(7)
79 %

Optimum heat transfer efficiency (8)
76%

Average particulate emissions rate (9)
2.3 g/h

Average CO (10)
69 g/h

Combustion technology
Non-catalytic

High-efficiency certified appliance
Yes, EPA 2020 approved

Maximum log length
20"

Log positioning
Loading over width

Chimney diameter
12'

Baffle type
C-Cast or equivalent

Approved for an alcove installation
Yes, with fresh air intake

Shipping Weight
506 lb (230 kg)

Door type
Ceramic glass

Glass surface – dimensions (Width X Height)
19 5/8" X 11 7/8"

Glass air-wash system
130

Overall dimension (Height)
36 7/8"

Overall dimension (Width)
27 1/8"

Overall dimension (Depth)
25"

Door opening – dimension (Height)
8 3/4"

Door opening – dimension (Width)
17 1/2"

Firebox – dimension (Height)
11 7/8"

Firebox – dimension (Width)
21"

Firebox – dimension (Depth)
16 1/2"

Firebox lined with refractory bricks for better heat distribution
Yes

Model
Pedestal

Steel thickness – body
3/16"

Steel thickness – top
5/16"

USA standard (emissions)
EPA

Canadian Standard (emissions)
CSA B415.1-10

USA standard (safety)
UL 1482,UL 737

Canadian standard (safety)
ULC S627

Tested and listed as per applicable standards
Limited lifetime

Minimum clearances to combustibles*(Data expressed in inches. 1 inch = 25.4 mm)
Single wall pipe

Double wall pipe
Clearance – back wall

14 1/2"
6"

Clearance – corner
10"

7"
Clearance – side wall

17"
17"

16"
16"

Clearance – top (measured from the platform on which the appliance is installed)**
84"

84"
