STRATFORD II WOOD FIREPLACE

STRATFORD II WOOD FIREPLACE

$4,699.00

SKU: OB04007 Category: Tags: , ,

Description

Let yourself be charmed by the timeless beauty of this non-catalytic wood fireplace, which performs particularly well and meets the EPA’s most restrictive emissions standards.

The Stratford II offers you more, including a 2.5 cubic foot firebox that’s easy to access through double-cast iron doors. This unit will impress you with its distinctive style and exceptional heating capacity.

Discover the additional qualities of the Stratford II wood fireplace

APPROVED FOR THE ISLAND OF MONTREAL

Government incentives may apply to this product.
LEARN MORE

*Any installation must be done according to the data and drawings detailed in the owner’s manual.

97% of the last 49 product owners who have registered their warranty are satisfied with this product.



Additional information

Heating area

200 Ft2, 750 – 2
Maximum heat output

000 BTU/h (23.4 kW), 80
Fuel Type

Dry cordwood (16" recommended)
Overall firebox volume-ft³

2.5
EPA loading volume-ft³

1.94
Maximum burn time ()

8 h
68 % (LHV) (5)

Optimum overall efficiency (6)(7)
70%

Optimum heat transfer efficiency (8)
68%

Average particulate emissions rate (9)
1.2 g/h

Average CO (10)
98 g/h

Combustion technology
Non-catalytic

High-efficiency certified appliance
Yes, EPA 2020 approved

Maximum log length
20"

Log positioning
Loading over width

Chimney diameter
6"

Type of chimney
15'

Baffle type
C-Cast or equivalent

Approved for a mobile home installation
No

Shipping Weight
468 lb (212 kg)

Door type
Ceramic glass

Glass surface – dimensions (Width X Height)
22 1/4" X 12 1/2"

Glass air-wash system
176

Overall dimension (Height)
40 5/8"

Overall dimension (Width)
36 3/4"

Overall dimension (Depth)
29 3/4"

Door opening – dimension (Height)
10 1/2"

Door opening – dimension (Width)
25 3/8"

Firebox – dimension (Height)
12 1/8"

Firebox – dimension (Width)
20 3/8"

Firebox – dimension (Depth)
12 7/8"

Moulded refractory bricks
Yes

USA standard (emissions)
EPA

Canadian Standard (emissions)
CSA B415.1-10

USA standard (safety)
UL 127

Canadian standard (safety)
ULC-S610

Tested and listed as per applicable standards
Limited lifetime

American Metal
HSS

AC Triple Wall
HS

AC Triple Wall
DuraTech

1" Solid Pack
DuraTech Canada (DTC)

1" Solid Pack
DuraPlus HTC

2" Solid Pack
DuraTech Premium

2" Solid Pack
DuraPlus

AC Triple Wall
Temp Guard

1" Solid Pack
Champion Chimney System

1" Solid Pack
Rockford Chimney Systems

1" Solid Pack
Ventis

1" Solid Pack
Nexvent

1" Solid Pack
S-2100+

2" Solid Pack
CF Sentinel (CF)

2" Solid Pack
Super Pro 2100 (ALT)

2" Solid Pack
Super Vent 2100 (JM)

2" Solid Pack
6" (15 cm)

Minimum clearances to combustibles*(Data expressed in inches. 1 inch = 25.4 mm)
United-States

Clearance – top (measured from the platform on which the appliance is installed)**
80 %

80"
8"

Clearance – side wall
13"

13"
16"

Clearance – from the shelf to the base of the fireplace
58"

58"
American Metal

HS
DuraVent

DuraPlus
AC Triple Wall

6" (15 cm)
Metal Fab

Temp Guard
Olympia Chimney

Rockford Chimney Systems
1" Solid Pack

6" (15 cm)
2" Solid Pack

6" (15 cm)
Selkirk

CF Sentinel (CF)
